Heavy-Duty Industrial Floor Fan,High-Velocity Stand Fan with 3-Speed Control,All-Metal Construction for warehouse,Workshop&Commercial Use

1. Instructions for Use

1.1 Pre-Use Preparation

1. Unpack and Inspect: Remove all packaging materials. Check that all parts (base, stand pole, motor head, fan blades, safety grille, screws) are included and undamaged.

2. Assembly:

   • Attach the stand pole to the base and tighten the securing screw.

   • Mount the motor head onto the top of the stand pole, then tighten the height-adjustment knob.

   • Install the rear safety grille onto the motor shaft, then fit the fan blade and secure it with the blade nut.

   • Attach the front safety grille to the rear grille and fasten all clips or screws to ensure it is locked in place.

3. Placement: Position the fan on a flat, stable, dry surface to prevent tipping or movement during operation. Ensure there is at least 30 cm of clearance around the fan for proper airflow.

1.2 Operation

1. Plug the power cord into a properly grounded electrical outlet.

2. Speed Control: Use the control switch (usually located on the motor head or stand) to select your desired speed (typically Low/Medium/High).

3. Oscillation Function: To activate the oscillation feature, push down the oscillation knob on the motor head. To stop oscillation, pull the knob up.

4. Adjustment: Tilt the fan head up or down to adjust the airflow angle. Use the height-adjustment knob to set the stand to your preferred height.

5. Shutdown: Turn the speed control to the "Off" position, then unplug the fan when not in use.

2. Important Safety & Usage Precautions

• General Safety

  • Never leave the fan unattended while operating, especially around children or pets.

  • Do not insert fingers, pencils, or any objects through the safety grille while the fan is running. The rotating blades can cause serious injury.

  • This fan is designed for dry, indoor or semi-outdoor use only. Do not use it in bathrooms, kitchens, or other high-moisture areas, and do not expose it to rain or water.

  • Unplug the fan before cleaning, assembling, disassembling, or moving it.

  • Do not operate the fan if the power cord or plug is damaged, if the motor housing has been dropped or damaged, or if the fan has been submerged in water. Contact customer service immediately.

• Usage Restrictions

  • Do not use the fan with extension cords unless the cord is rated for the fan's power consumption. Overloaded cords can overheat and cause fire hazards.

  • Do not place the fan near open flames, heat sources, or flammable materials.

  • Do not cover the fan or block the air intake/outlet grilles during operation. This will cause overheating and motor damage.

  • Do not use the fan for any purpose other than its intended use (e.g., do not use it to blow dust or debris).

• Environmental Considerations

  • Operate the fan in a well-ventilated area. Avoid using it in extremely dusty environments, as dust buildup can damage the motor over time.

3. Cleaning, Maintenance & Repair

3.1 Regular Cleaning & Maintenance

1. Cleaning the Grille and Blades:

   • Unplug the fan and let it cool completely.

   • Remove the front grille and fan blade according to the assembly instructions.

   • Wipe the grille and blades with a soft, damp cloth. For stubborn dust, use a mild detergent. Do not use abrasive cleaners.

   • Dry all parts thoroughly before reassembling the fan.

2. Motor Housing & Stand:

   • Wipe the exterior of the motor housing and stand with a dry or slightly damp cloth. Do not immerse the motor housing in water, as this will cause electrical damage.

   • Periodically check and tighten all screws, bolts, and knobs to prevent loosening from vibration.

3. Storage:

   • If storing the fan for an extended period, clean it thoroughly and store it in a cool, dry place, preferably in its original packaging to protect it from dust and damage.
